Máy POS The Ethan E5 là giải pháp hoàn hảo cho tiêu chí hiệu quả chi phí và hiệu suất vượt trội ngày nay. Máy sử dụng 5 dây điện trở ELO cho hoạt động đáng tin cậy tại các điểm bán lẻ. Màn hình linh hoạt và có thể được điều chỉnh để đáp ứng các yêu cầu của môi trường làm việc treo tường hoặc VESA góc nghiêng rộng. Sản phẩm luôn có mặt trên toàn bộ hệ thống của Việt Easy. Hãy đến ngay với chúng tôi để được mua những sản phẩm tốt nhất cả về giá cả lẫn chất lượng.
Thông số kỹ thuật máy POS The Ethan E5
Item | E5-1-K | E5-1-A |
Display | 15.6”, Resolution 1366 x 768, 15.6” Resolution 1920 x 1080 (Optional) | |
Touch | 15.6” Pcap Touch | |
CPU | Intel Celeron 3965U (KABYLAKE-U Co-lay) | Intel Celeron J3455 (Apollo Lake) |
Intel® Core™ i3-7100U (KABYLAKE-U Co-lay) | ||
Intel® Core™ i5-7300U (KABYLAKE-U Co-lay) | ||
Memory | DDR4 Standard Spec: 4GB, 8GB, 16GB | DDR3L Standard Spec: 4GB, 8GB |
Storage | HDD Standard: 500 GB; SSD Standard: 64G / 128 GB / 256 GB | |
External I/O Interface | 2 x Serial ports, RS232 (RJ45), 0V/5V/12V selection by BIOS (COM1, COM2) | |
2 x LAN, ( IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45) | ||
1 x RJ11 port supports 2 cash drawers with 24V / 12V by jumper setting | ||
1 x DC+12V out | ||
4 x USB Type-A ports (USB3.0/2.0) | ||
1 x DC +12V input power-jack | ||
1 x Audio (1 * Line-out) | ||
1 x HDMI port | ||
1 x VGA | ||
Expansion I/O (Factory options) |
1 x Serial Port, RS-232 (DB9, COM3, 0V/5V/12V selection by jumper) + 2 x USB Type-A | |
2x Serial Ports, RS-232 (DB9, COM3 & COM4, 0V/5V/12V selection by jumper) | ||
1 x Serial Port, RS-232 (DB9, COM3, 0V/5V/12V selection by jumper) + 1 x DB25 LPT | ||
2 x USB Type-A (USB3.0/2.0) + Powered USB (12Vx1 + 24Vx1) | ||
Optional Powered USB on the stand | 4 x Powered USB (3x12V + 1x24V, on the SP-1060 stand or PS-103) | |
Remark: NO optional powered USB on the stand if the powered USB is installed on the POS PC. | ||
USB 2.0 at the side | USB 2.0 port at the side of POS PC for easy maintenance | |
RAID Function | RAID 0/1 (RAID function on Chip, 2nd SATA storage on SP-1060 stand or PS-103) | N/A |
Speaker | 1*Speaker 3W | |
Optional Peripheral | MSR, IC Card Reader, Fingerprint, RFID, i-Button, VFD, Camera, UVC Light | |
WIFI/BT | Option | |
Display Support | 3 Independent Displays (Main Display + VGA + HDMI) | |
Spill & Dust resistant | IP54 Certified | |
Expansion | Mini-PCIe interface | |
Optional M.2 SSD | M.2 PCIe SSD | M.2 SATA SSD |
SW | 1. Windows 10 IoT LTSB (64bit) | |
2. Linux (Ubuntu) | ||
3. Intel V-Pro (i5 CPU only) | N/A | |
Power Adaptor | AC-In 100~240V / DC-Out 12V, 90W / 180W | |
Reliability | System Operating Temperature: 0~35˚C for HDD | |
System Operating Temperature: 0~40˚C for SSD | ||
System Humidity: 15%~80% | ||
Storage Temperature: -20~60˚C | ||
Dimensions | W392 x H320 x D250mm | |
Weight | 8.5KGS |
